Red And Blue Light Superimposed Incubator Shaker
Red And Blue Light Superimposed Incubator Shaker

Red And Blue Light Superimposed Incubator Shaker

LIS-6BRL Series
LABOAO supplied the LIS-6BRL series incubator shaker mainly used for plant or plant cell culture, using advanced frequency conversion refrigeration technology and high-precision temperature control technology with invention patents.
  • AmplitudeΦ26/50mm
  • Oscillation modeOrbital
  • Capacity381L
  • Rocking plate size900x560mm
Request QuotationChat Now
  • WhatsApp

    WhatsApp Chat

  • WeChat

    WeChat Chat

Download

OVERVIEW

The red and blue light superimposed incubator shaker is suitable for tissue culture and plant development, growth and cultivation. This series is equipped with red and blue light function, built-in top light, special biological light source, providing the light required for the cultivation of laboratory plants, seeds, plant cells, microorganisms, viruses, etc., with good spectral characteristics and low heat. The ratio of red and blue light can be flexibly set. It can run independently with 24-segment programming, and can also run with synchronized temperature programming.

FEATURES

1. Microcomputer program control: temperature and illuminance, which can simulate the temperature and humidity changes during the day and night (optional), and you can also choose a sufficient and stable light source for the growth environment.

2. Multi-segment programming: 24 segments can be programmed, each segment can be set for 999 hours.

3. Frequency conversion refrigeration technology: quiet, durable and energy-saving.

4. Convenient cleaning: the mirror surface stainless steel liner, the arc angle design, is convenient for cleaning in the box.

5. Independent limit temperature protection: automatically interrupt when the limit temperature is exceeded to ensure safety.

6. CO2 infrared sensor: accurate, sensitive, not affected by temperature and humidity, long life.

7. Remote monitoring: optional mobile Wifi remote monitoring or computer remote monitoring (optional).

8. Active humidification technology: stable humidity, parameter quantification (optional).

9. Can be washed with water: the inner cavity and the rocking plate can be washed with water for easy cleaning.

SPECIFICATIONS

Model

LIS-6BRL

LIS-6BRLT

LIS-6CBRL

LIS-6C5BRL

LIS-6C5BRLT

Rocking plate size

900x560mm

Number of flask holders/adhesive pads

Flask holder50mlx135 /   100mlx60 / 150mlx60 / 200mlx60 / 250mlx60 /   500mlx34 / 1000mlx22 / 2000mlx15 / 3000ml(Thomson)x12   / 5000ml(Thomson)x6
  Adhesive pad
50mlx187 / 100mlx112 / 150mlx104 /   200mlx84 / 250mlx77 / 500mlx40 / 1000mlx28 / 2000mlx15   / 5000ml(Thomson)x8

Capacity

381L

Maximum load

20kg

Temperature control range

10~60 (minimum 4) below room temperature when   maximum light intensity

Temperature control accuracy

±0.1

Temperature uniformity

±0.8 (@37)

Rotation speed

0  (Stop)30~300rpm

Speed accuracy

±1rpm

Vibration amplitude

φ26mm

φ50mm

CO2 sensor

no

IR (Infrared)

CO2 concentration control range

no

0~20%

CO2 concentration control accuracy

no

±0.1%

Temperature recovery time after opening the door for   30s and restarting

no

≤6min (@37)

CO2 concentration recovery time after opening the door   for 30s and restarting

no

≤6min (@5%)

Humidity type

no

Natural humidification

Maximum humidity

no

95%

Programmable number of segments

12

Light intensity

Red light: 0~2500Lux; blue light: 0~2500Lux (10cm on   the rocking board)

Light intensity accuracy

25Lux

Light color

Red light, blue light

Illumination wavelength

Red light: 640~660nm, blue light: 430~450nm

Uniformity of illumination

±500Lux (at   maximum light intensity)

Sterilization

UV sterilization

Door opening method

Open down

Open up

Open down

Open down

Open up

Set parameter protection

password protection

Illumination, temperature, speed can be multi-segment   programming operation

Have

Temperature and light cycle

Have

Curve display type

Temperature curve, speed curve

Temperature curve, speed curve, CO2 concentration   curve, humidity curve

Display method

Capacitive, 10-inch color touch screen

Timing range

0~999 hours 59 minutes

U disk export data

Have

The number of days of operating parameters can be   queried on the screen

Within 7 days

Operating data storage period

More than 912 days

Operating data storage interval

1 minute

Data storage content

Running time, temperature parameter, speed parameter,   running status

Operating time, temperature parameters, speed   parameters, humidity parameters, CO2 concentration, operating status

Automatic defrost

Have

Automatically turn off the screen display

Have

Automatic screen lock

Have

The third layer of rocking board height

1496mm

Rocking plate with guide rail

Have

Noise level

55dB (when   cooling)

Can be rinsed with water

Yes

Interface language

Can switch between Chinese and English display

Automatic call recovery function

Have

Motor type

Brushless DC motor

Heating power

≤850W

Cooling power

70~180W

Work rate

≤1200W

≤1250W

Power supply

AC 220V±22V50Hz / 60Hz

Active humidification (optional)

no

10%~95% above ambient humidity optional

WiFi mobile phone monitoring (optional)

Optional

Computer monitoring (optional)

Optional

Net weight

293kg

298kg

Working height of inner cavity

305mm

Dimensions

1400x886x (600+80 foot height)mm
