The turntable mixer is specially designed for different application environments such as schools, laboratories, and hospitals. It is used for blood routine experiments conducted by the whole blood method and other mixing applications. The product has three models of continuous constant speed operation, timing speed regulation operation and large capacity.
1. The inclination angle can be adjusted according to the needs of the use environment;
2. Different test tube fixtures can meet different usage requirements;
3. All products can be adapted to the cold room and incubator environment;
4. Two models of LTR-04U and LTR-05U have adjustable speed, continuous operation and timing functions.
Model | LTR-03 | LTR-04U | LTR-05U |
Product name | Rotary plate type test tube rotating mixer | Large capacity test tube turntable mixer | |
Main distinguishing features | Fixed speed | Speed display, adjustable speed | Speed display, adjustable speed, large capacity |
Rotating speed | 20rpm | 2~80rpm | 5~80rpm |
Speed setting accuracy | NA | 1rpm | |
Rotation angle | 90°~180° | 95°~180° (6 gears): 95°, 112°, 129°, 146°, 163°, 180° | |
Timing range | NA | 0~99h59min | |
Rotating disc diameter | Φ250mm | 15x50ml turntable, Φ290mm diameter | |
Turntable capacity | 12x50ml/18x15ml/48x2ml/9x50ml | 50x9~11mm test tube (1.5/2ml), | |
Digital display method | NA | LCD | LED |
Automatic call recovery function | YES | ||
Standard | No turntable, need to be equipped separately | ||
Ambient temperature | 5℃~40℃ | ||
Relative humidity | ≤80% | ||
power supply | AC220V, 50Hz | AC100~240V, 50/60Hz | |
Maximum power | 11W | 6W | 8W |
Dimensions (WxDxH) | 334x215x405mm | 440x296x466mm | |
Net weight | 3.5kg | 4kg | 8.1kg |
Enclosure protection level | IP21 | ||
Certification | NA | cCSAus, CE, RoHS, WEEE | |
Accessories
Name | Model | Capacity | Suitable for |
50ml test tube clamp (Φ250mm) | TRA15 (optional) | Can hold 50ml test tube | LTR-03, LTR-04U, LTR-05U |
5/10/15/20ml test tube clamp (Φ250mm) | TRA16 (optional) | Can hold 5ml/10ml/15ml/20ml test tube | LTR-03, LTR-04U, LTR-05U |
2ml test tube holder | TRA17 (optional) | Can hold 1.5ml/2ml test tube | LTR-03, LTR-04U, LTR-05U |
Multi-purpose turntable assembly | TRA19 (optional) | 9x50ml+9x15ml+12x2ml test tube holder | LTR-03, LTR-04U |
2ml turntable assembly | TRA20 (optional) | 48x2ml test tube holder | LTR-03, LTR-04U |
15ml turntable assembly | TRA21 (optional) | 18x15ml test tube holder | LTR-03, LTR-04U |
50ml turntable assembly | TRA22 (optional) | 12x50ml test tube holder | LTR-03, LTR-04U |
2.0ml turntable assembly | TRA23 (optional) | 50x2ml | LTR-05US |
15ml turntable assembly | TRA24 (optional) | 30x15ml | LTR-05US |
50ml turntable assembly | TRA25 (optional) | 15x50ml | LTR-05US |
10 / 15ml + 5 / 7ml turntable assembly | TRA26 (optional) | 10x10ml / 15ml + 20x5ml / 7ml | LTR-05US |
